VENTILATED ROOFS

Panel composed of sintered expanded polystyrene, selfextinguishing, cut in blocks and 1 cm OSB wood.
Reduced size 1,22 m x 2,44 m.
Panel total thickness of 90 mm.
Ventilation chamber thickness of 4 cm.
Insulation material thickness 4 cm. On request also available thicknesses from 5 to 20 cm.
Extreme light weight of the panel pack, only 6,5 kg/m²
Remarkable compressive strength: approx. 100 kPa.
With 2 sided shiplap edge.

Panel composed of sintered graphite enhanced polystyrene, cut in blocks and 1 cm OSB wood.
Reduced size 1,22 m x 2,44 m.
Panel total thickness of 90 mm.
Ventilation chamber thickness of 4 cm.
Insulation material thickness 4 cm. On request also available thicknesses from 5 to 20 cm.
Extreme light weight of the panel pack, only 6,5 kg/m².
Remarkable compressive strength: approx. 100 kPa.
With 2 sided shiplap edge.
